OGMT Damp Proof Membrane

OGMT DPM 250μm is a blown film of extruded low-density polyethylene, suitable for use in concrete floors not subject to hydrostatic pressure. OGMT’s low cost DPM range offers fit-for-purpose film, without compromising on product strength and performance.

Categories: , ,

Manufacturer: OGMT Branded Products

250μm DPM (Clear) for residential and low-rise buildings

FEATURES:                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     OGMT DPM 250μm is a blown film of extruded low-density polyethylene, suitable for use in concrete floors not subject to hydrostatic pressure. OGMT’s low cost DPM range offers fit-for-purpose film, without compromising on product strength and performance.

APPLICATIONS:

OGMT DPM 250μm is suitable for use below concrete floor slabs in most domestic or low-rise buildings site conditions, not subject to hydrostatic pressure.  If hydrostatic pressure exists please contact technical support for advice. For jointing adjacent sheets, double sided (10m x 50mm) and single sided (33m x 50mm) jointing tape should be used.

IMPORTANT:

When a Vapour Con  trol Layer is required please consult OGMT Technical. We do not recommend OGMT DPM 250μm for this purpose.

INSTALLATION:

OGMT Damp Proof Membranes form an effective barrier to the passage of moisture from the ground. The DPM must be continuous and the membrane should be installed on a compacted sand blinding layer or smooth concrete float finish.  Care should be taken to ensure that the membrane is not stretched or displaced when placing sand, concrete or screed over the membrane.





  • Blown film of extruded low-density polyethylene
  • Suitable for use in concrete floors not subject to hydrostatic pressure.
  • low cost DPM range offers fit-for-purpose film, without compromising on product strength and performance.
COMPOSITION
LDPE
Construction Film
TYPE
Food Grade
ANTISTATIC TREATMENT
OK
Antistatic
EASY OPEN
OK
Y
UV PROTECTION
OK
Y
COLOUR
COLOURLESS
PHYSICAL PROPERTIES
STANDRDS ASTM D882
YIELD STRESS
Machine kg/cm2 Transverse kg/cm2
336 433
BREAK STRESS
Machine kg/cm2 Transverse kg/cm2
494 562
ELONGATION AT BREAK
Machine % Transverse %
1,200 1,380
THICKNESS
Micron
250 +/- 10
WIDTH
mm
3,600
CUT LENGTH
mm
Roll
TYPE OF CORE
PLASTIC / PAPER
Paper
CORE DIAMETER
mm ID
76
FILM MAX WIDTH
Mm
3,660 +/ – 3
CALCULATED DENSITY
Kg/dm3
0.92
